Eaton's Bussmann



Product description:

Eaton answers the call for compact drives, power conversion and UPS equipment with our new Bussmann® series compact high speed fuses.



Our 50-400 amp fuses use up to 48% less enclosure space when compared with traditional high speed, round body fuses. What's more, the innovative design allows for a significantly smaller package without compromising heat rise performance.



With the most compact high speed 500Vac/dc fuses in the industry, we help you achieve smaller overall equipment designs.



Features and benefits:

• Using up to 48% less enclosure space allows for a reduction in the overall size of power conversion equipment

• Innovative design allows for a significantly smaller package without compromising heat rise performance, preventing extensive equipment redesign.

• Global acceptance with UL®, CSA® and IEC® for products sold worldwide.

• Bolt-on design provides design flexibility for installation in fuse blocks or direct mounting on busbars.



Specifications Ratings

• Volts - 500Vac/dc

• Amps-50-400A

• Interrupting rating

• Max AC - 200kA

• Min AC 400%

• Max DC - 50kA

• Min DC 800%

• Conforms to IEC® aR specifications for shortcircuit protection



Agency information

• UL Recognized, File E56412, Guide JFHR2

• CSA Component Acceptance, Class 1422-30, File 53787

• IEC aR (self certified)

• CE

• RoHS compliant

• REACH declaration available upon request



Catalog numbers:


    Watts loss / percent of rated current
Catalog number Amps AC/DC I2t (A2s) pre-arcing AC* I2t (A2s) total clear DC** I2t (A2s) total clear @ 80% @ 50%
CHSF-50 50 304 1875 935 3.8 1.3
CHSF-60 60 438 2700 1346 4.5 1.5
CHSF-70 70 596 3675 1833 5.3 1.8
CHSF-80 80 778 4800 2394 6.1 2
CHSF-100 100 1216 7500 3740 7.6 2.5
CHSF-125 125 2042 12,721 6465 12 3.6
CHSF-150 150 2941 18,318 9309 14.3 4.3
CHSF-175 175 4003 24,933 12,671 16.7 5.1
CHSF-200 200 5228 32,566 16,550 19.1 5.8
CHSF-225 225 6835 48,028 21,278 26.1 7
CHSF-250 250 8438 59,293 26,270 29 7.8
CHSF-300 300 12,151 85,382 37,828 34.8 9.4
CHSF-350 350 16,539 116,215 51,488 40.6 10.9
CHSF-400 400 21,603 151,791 67,250 46.4 12.5
* @ 200kA/500Vac.
**@ 50kA/500Vdc.













PRE - ORDER NOW
series: CHSF series, compact high-speed fuse
Current: 50-400A
Voltage: 500Vac/dc
Breaking capacity:- Max AC 200kA
-Min AC 400%
-Max DC 50kA
-Min DC 800%
Approvals:- UL Recognognized, File E56412, Guide JFHR2
-CSA Component Acceptance, Class 1422-30, File 53787
-IEC aR (self certified)
-RoHS compliant
